Description
Aluminum alloy sacrificial anode is referred to as aluminum anode. Commonly used aluminum anodes are Al-Zn-In and Al-Zn-Hg series anodes. The aluminum anode is directly fixed on the protected structure without filler. Because the performance of aluminum anodes is affected by the chemical composition of the alloy, we provide combinations of aluminum alloys with different compositions to meet customer needs.
Application:
Aluminum anodes are mostly used for cathodic protection of metal structures in seawater environments or the inner bottom of crude oil storage tanks, and cannot be used in soil environments with low chloride ion content. Aluminum alloy sacrificial anodes are widely used in ship hulls, ballast water tanks, seawater pipelines, port and dock facilities, marine engineering, seaport engineering, seaport facilities, drilling platforms, condensers, pipelines in sea mud, cables and other facilities for cathodic protection of metal corrosion .
Specification(Customized available):
Iron core size
Specification(mm)
Weight(kg)
Inside diameter x W x thickness x gap(mm)
5x50
Φ1020x200x35x51
68
5x25
Φ819x60x30x51
13
5x50
Φ624x80x30x51
17
5x50
Φ513x100x30x51
17
5x50
Φ487x200x45x51
41
5x50
Φ470x480x25x51
50
5x50
Φ436x480x38x51
70
5x50
Φ420x413x45x51
69
5x50
Φ385x150x59x51
32
5x50
Φ335x505x38x51
56
5x50
Φ280x250x45x51
29
5x50
Φ252x250x45x51
26
Packing & Shipment:
